Epson WorkForce Pro WF-R5190DTW specifications
Printing Method
A4: 30ppm colour/ 34ppm mono
Nozzle Configuration
30 Pages/min Color (plain paper 75 g/m²), 34 Pages/min Monochrome (plain paper 75 g/m²)
Minimum Droplet Size
Monochrome 7 Seconds, Color 7 Seconds
Ink Technology
4800 x 1200 dpi
Functions
Print, Copy, Scan, Fax
Print speed ISO/IEC 24734
A4: 30ppm colour/ 34ppm mono
Print speed
30 Pages/min Color (plain paper 75 g/m²), 34 Pages/min Monochrome (plain paper 75 g/m²)
Time to first print (TTFP)
Monochrome 7 Seconds, Color 7 Seconds
Resolution
4800 x 1200 dpi
Colours
Magenta, Yellow, Cyan, Black
Paper sizes
A4, A5, A6, B5, C4 (Envelope), C6 (Envelope), No. 10 (Envelope), Letter, 10 x 15 cm, 13 x 18 cm, 20 x 25 cm, 16:9, Legal
Compatible Paper Weight
64 g/m2 - 256 g/m2
Duplex
Automatic
Standard Paper input
580 Sheets Standard, 80 Sheets MP tray, 500 Sheets paper tray
Output Tray Capacity
150 Sheets
Paper Tray Capacity
580 Sheets Standard, 580 Sheets Maximum
Network Printing Protocols
LPR, FTP, IPP, LDP, Port 9100, WSD, Net BIOS over TCP/IP, TCP/IPv4, TCP/IPv6, IPSec
Network Management Protocols
SNMP, HTTP, DHCP, BOOTP, APIPA, DDNS, mDNS, SNTP, SSDP, Ping, SLP, WSD, LLTD, IEEE 802.1X
Interfaces
Wi-Fi Direct, Wireless LAN IEEE 802.11b/g/n, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), Hi-Speed USB - compatible with USB 2.0 specification
WLAN Security
WEP 64 Bit, WEP 128 Bit, WPA PSK (AES), WPA2 Enterprise
Energy Use
25 Watt (standalone copying, ISO/IEC 24712 pattern), 2.3 Watt (sleep mode), 6.2 Watt (ready), 0.3 Watt (Power off)
Supply Voltage
AC 220 V
Product dimensions
664 x 435 x 413 mm (Width x Depth x Height)
Product weight
24.25 kg
Compatible Operating Systems
Mac OS 10.5.8 or later, Mac OS 10.6+, Mac OS 10.7.x, Mac OS 10.8.x, Microsoft Windows XP (Home Edition / Prof / Prof X64 / Vista), Windows Server 2003 (32/64bit), Windows Server 2008 (32/64bit), Windows Server 2008 R2, Windows Server 2012 (64bit)
Sound Power
Operation: 6.6 B (A)
Sound Pressure
Operation: 52 dB (A)
Mobile and Cloud printing services
Apple AirPrint, Google Cloud Print
Power Supply
220V
What's in the box
Driver and utilities (CD), Individual Ink Supply Units, Main unit, Power cable, Quick Setup Guide, Warranty Documents
Security Functions
Limit access function with Epson Web Config, Secure confidential printing with PIN code release, IPsec, IEEE802.1x, SSL (Server authentication), Panel Admin Mode
Emulations
PDF 1.7, Adobe® Postscript 3®, ESC/P-R, PCL5e, PCL5c, PCL6
