Oki ES8434 specifications
Print speed
A4: 36ppm colour, 36ppm mono
Time to first print (TTFP)
6.3 seconds colour, 6.3 seconds mono
Warm up time
Up to 20 seconds from power on & up to 9.9 seconds from power save
Printer fonts
Scalable: 87 PCL Fonts and 80 PostScript fonts, PCL Bitmap fonts, LinePrinter, OCR-A/B, USPS ZIP Barcode
Resolution
ProQ2400 Multi-level Technology, 1200 x 600dpi, 600 x 600dpi
Enhancements
Auto Color Balance, Photo Enhance via driver (Windows PLC6 driver only)
Memory (RAM)
Standard RAM: 1GB
Operating temperature/ humidity
10°C to 32°C (17°C to 27°C recommended) / 20% to 80% RH (50% to 70% RH recommended)
Storage temperature/ humidity
-10°C to 43°C, 10% to 90% RH
Power supply
Single phase 220-240VAC, frequency 50/60Hz +/-2%
Power consumption
Typical: 680W; Max: 1118W; Idle: 13W; Power Save: <11W; Deep Sleep: <1.0W; Auto-Off: <0.15W
Noise level
Operating: <54dB(A); Standby: 32dB(A); Power save: Background Level
Dimensions (HxWxD)
449 x 552 x 360mm
Weight
40kg
Connectivity
Hi-Speed USB, Wireless, NFC & Ethernet
Printer language
PCL6 (XL3.0 & PCL5c) PostScript3 emulation, PDF v1.7, SIDM(IBM-PPR, EPSOM-FX)
Paper capacity
Tray 1: 300 sheets of 80gsm; Multi-purpose tray: 100 sheets of 80gsm
Paper capacity optional tray
Tray 2: 535 sheets of 80gsm
Paper capacity optional tray
Tray 3: 535 sheets of 80gsm
Paper capacity optional tray
Tray 4: 535 sheets of 80gsm
Maximum paper capacity
2540 sheets of 80gsm
Paper sizes
Tray 1: A3, A4, A5, A6, B5, A6; Tray 2: A3, A4, A5, B5; Multi-purpose tray: A3, A4, A5, B5, A6, Envelopes (C5, C4, DL, Com-10); Duplex: A3, A4, A5, B4, B5
Paper weight
Tray 1: 64 to 220gsm; Tray 2/3/4: 64 to 176gsm; Multi-purpose tray: 64 to 256gsm; Duplex: 64 to 220gsm
Duplex
Standard
Paper output
Face Down: 250 sheets of 80gsm; Face Up: 100 sheets of 80gsm
